Product ZoneBattery Chargers : Li-ion Battery Chargers >


 ● Smart Charging - detects the battery status and activates the

deeply discharged batteries. multiple charging protections function effectively to prevent overcharge and undercharge, ensureing charging safety and improve the cycle life of the battery

 ● Four Charging Current - adapt to different charging current

according to the battery type

 ● Four Independent Charging Channels- charges 1 -4 batteries

 ● LED Indicator- indicate each batteries’ charging status

 ● Smart Detection- automatically identifies Li-ion / Ni-MH batteries

 ● USB Output- can perform as a charging device, charging

other devices when placing one suitable battery at the right column

 ● 3 Levels of Safety Protection - over-charging, over-discharging, short circuit and reverse polarity protection

Battery Type Battery Capacity Charging time (Appr.)
26650 Lithium-ion 5000 mAh 12 h
18650 Lithium-ion 2500 mAh 6 h
18650 Lithium-ion 2000 mAh 5 h
18500 Lithium-ion 1500 mAh  3.5 h
17335 Lithium-ion 700 mAh 100 min
Ni-MH AA 2000mAh 5 h
2.5 h


Input: USB-C 5V

Charging Voltage:

1.42V  4.2V±0.05V,   3.65±0.05V  4.35±0.05V

Charging Current:

1 PCS: 2000mA(4th Slot Only)/1000mA/700mA/500mA

2 PCS: 1000mA/700mA/500mA

3 PCS: 700mA/500mA

4 PCS: 500mA

Mobile Power Function

USB output: 5V,1A  (Requires lithium battery at the 4th slot)
